External Spline Cutting
Milled, hobbed or shaped splines on shafts and rotating components.
SPLINE MACHINING · INTERNAL & EXTERNAL · FUNCTIONAL FIT
Precision Spline Machining Services
Manufacture internal and external splines, splined shafts and torque-transmission interfaces with tooth form, datum relationships, heat treatment and fit controlled together.
- Drawing-defined manufacturing route
- Prototype through repeat production
- Inspection evidence available by agreement
Upload STEP or Parasolid files with a controlled PDF drawing, material, quantity, finish and inspection requirements.
INT / EXTSPLINE TYPES
SHAFTDATUM CONTROL
HEATROUTE PLANNED
FITFUNCTIONAL CHECK
PROCESS BEFORE MACHINE
Engineer the route around the feature most likely to fail.
Manufacture internal and external splines, splined shafts and torque-transmission interfaces with tooth form, datum relationships, heat treatment and fit controlled together. Mockup connects DFM, process selection, workholding and inspection before material is released.
01 / CAPABILITIES
Manufacturing Capability Built Around the Critical Feature
Each route is reviewed from the drawing, functional datums, material behavior, quantity and required evidence.
ENGINEER REVIEWED
ENGINEER REVIEWED02
Internal Spline Machining
Broaching, shaping, wire EDM or reviewed alternative routes.
ENGINEER REVIEWED03
Splined Shaft Machining
Journals, shoulders and spline geometry controlled from functional datums.
ENGINEER REVIEWED04
Involute Splines
Standard- and drawing-defined tooth forms with class and fit review.
ENGINEER REVIEWED05
Straight-Sided Splines
Parallel-sided and serrated interfaces for torque and location.
ENGINEER REVIEWED06
Hardened Components
Pre-cut, heat-treat and finish strategies planned around final fit.
02 / PROCESS SELECTION
Select the Route From the Functional Risk
Compare manufacturing routes against geometry, material, quantity and the feature that controls acceptance.
External spline route
Internal spline route
MOVEMENT
Open tool access
Enclosed access
COMPLEXITY
Milling, hobbing or shaping
Broaching, shaping or EDM
SURFACE QUALITY
Flexible length
Bottom clearance critical
EFFICIENCY
Shaft workholding
Bore datum control
BEST FOR
External torque interfaces
Couplings and hubs
COST & INVESTMENT
Quantity-dependent tooling
Tool/form economics
03 / CONTROLLED WORKFLOW
From Drawing Review to Delivered Evidence
Keep engineering assumptions, revision and acceptance criteria connected throughout the order.
Engineering Review
Confirm geometry, material, quantity, CTQ features and open questions.
Route & Workholding
Choose operations, tools, datums, fixture strategy and inspection points.
Machining & Control
Run the approved sequence with in-process checks where risk requires them.
Final Verification
Inspect the delivered condition and supply agreed records.
04 / TECHNICAL RANGE
Capability and Specification Reference
These values define the review inputs. The approved quotation and drawing control final capability.
SpecificationDescription
Spline formsInvolute, straight-sided, serrated and drawing-defined
ConfigurationInternal, external, through, blind and shaft-mounted
Required definitionStandard, module/pitch, pressure angle, tooth count and fit class
MaterialsSteel, stainless, aluminum, bronze and engineering alloys
InspectionPins, span, runout, profile and functional gauges as specified
ProductionPrototype, replacement, small batch and repeat production
05 / QUALITY CONTROL
Build Inspection Into the Manufacturing Route
A result is useful only when the functional requirement and the evidence used to accept it are aligned.
A result is useful only when the functional requirement and the evidence used to accept it are aligned.
- ✓Functional datumsRelate the spline to bearing seats, journals, shoulders and mating bores.
- ✓Tooth-form controlVerify effective geometry with the agreed analytical or functional method.
- ✓Thermal stabilityPlan heat-treatment allowance, straightening and final finishing.
- ✓Fit evidenceUse master or mating gauges when the interface requires functional proof.
06 / DESIGN FOR MANUFACTURING
Design Decisions That Improve Process Stability
Resolve access, datum and inspection questions before manufacturing release.
Use a complete callout
Modeled teeth alone do not define fit, class or inspection.
Provide cutter runout
Shoulder and blind-bottom clearance affect route feasibility.
Define centering
State flank, major-diameter or other centering requirements.
Share the mating part
Interface context helps resolve fit and gauge decisions.
07 / PART APPLICATIONS
Where This Capability Creates Value
Manufacturing routes are adapted to the functional geometry and program stage.
01 / ROUTE
Splined Shafts
Drive shafts and actuators related to journals and bearing seats.
02 / ROUTE
Hubs & Couplings
Internal splines for torque transfer and serviceable assembly.
03 / ROUTE
Robotic & Automotive Parts
Compact transmission interfaces with controlled backlash and alignment.
ENGINEERING REVIEW
Get a spline machining quote
Upload the current 3D model and controlled drawing with material, quantity, finish, critical characteristics and inspection requirements.
Upload CAD files↗Precision Spline Machining Services questions, answered.
Can Mockup machine internal and external splines?+
Yes, subject to geometry review. Routes can include milling, hobbing, shaping, broaching and wire EDM.
Which spline standards are supported?+
Common involute and straight-sided standards and complete customer-defined profiles can be reviewed.
How are splines inspected?+
Methods may include measurement over pins, span measurement, runout, profile data and functional gauges.
Can hardened splined parts be supplied?+
Yes, when heat-treatment distortion, finishing allowance, hardness and final fit are planned before production.
